Part Vds Min
(V)
ID@TC=25℃
(A)
RDS(on) Max PD@TC=25℃
(W)
Vgs
(±V)
Vth
(V)
Ciss Typ
(pF)
Qg Typ
(nC)
Configuration Package
10V(mΩ) 4.5V(mΩ)
HYG028N10NS1B 100 230 3.3 N/A 300 20 2~4 10320 176 single - N TO-263
HYG035N10NS2B 100 180 4 N/A 220 20 2~4 7270 115 single - N TO-263
HYG028N10NS1P 100 230 3.3 N/A 300 20 2~4 10320 176 single - N TO-220
HYG035N10NS2P 100 180 4 N/A 220 20 2~4 7270 115 single - N TO-220
HYG037N10LS2B 100 150 4.2 5.2 176.5 20 1~3 4350 82 single - N TO-263
HYG042N10NS1B 100 160 4.2 N/A 200 20 2~4 7040 119 single - N TO-263
HY029N10B 100 270 3.3 N/A 394.7 20 2~4 10800 148.7 single - N TO-263
HYG042N10NS1P 100 160 4.2 N/A 200 20 2~4 7040 119 single - N TO-220
HY029N10P 100 270 3.3 N/A 394.7 20 2~4 10800 148.7 single - N TO-220
HYG045N10NS1B 100 160 4.5 N/A 250 20 2~4 7877 117 single - N TO-263
HYG045N10NS1P 100 160 4.5 N/A 250 20 2~4 7877 117 single - N TO-220
HY029N10B6 100 280 3 N/A 405 20 2~4 10800 150 single - N TO-263-6
HYG050N10NS1MF 100 135 5.2 N/A 189.9 20 2~4 6359 100 single - N TO-220
HYG050N10NS1P 100 135 5.2 N/A 189.8 20 2~4 6359 100 single - N TO-220
HY029N10W 100 280 3 N/A 405 20 2~4 10800 150 single - N TO-247
HYG072N10LS1C2 100 80 7.5 11 75 +20/-12 1~3 2980 56 single - N PDFN8L(5x6)
HYG072N10LS1P 100 80 8 12 104 +20/-12 1~3 3070 54.3 single - N TO-220
HYG110N11LS1S 115 14 13.5 18.5 8.3 20 1~3 2806 46.9 single - N SOP8L
HYG080N10LS1C2 100 65 8.2 11.2 71 20 1~3 2070 30.2 single - N PDFN8L(5x6)
HYG092N10LS1MF 100 65 9.2 14 75 20 1~3 2410 51.9 single - N TO-220
